LCMS-2050 Single Quadrupole LC/MS

Single Quadrupole Mass Spectrometer

Add Bookmark

LCMS-2050 Single Quadrupole LC/MS
Request More Information

Compact, user-friendly LCMS solution enhances detection & speeds analysis

The space-saving LCMS-2050 is engineered for seamless operation,
so you can achieve reliable results with ease and convenience

The LCMS-2050 single quadrupole mass spectrometer combines the user friendliness of an LC detector with the performance of MS to provide a complete, streamlined, cost-efficient analytical solution.

The system enables enhanced detection in a short period of time because the ionization source combines heated electrospray (HESI) and atmospheric pressure chemical ionization (APCI). This combined dual ion source (DUIS) can analyze a wide range of compounds from multiple chemical classes.

Key Features

The LCMS-2050 single quadrupole mass spectrometer combines the user friendliness of an LC detector with the performance of MS to provide a complete, streamlined, cost-evcient analytical solution
  • Flexible combined dual ion source for enhanced detection
  • Small size for space and energy savings
  • Easy parameter settings for simplified MS and LC operation
  • Analysis of a wide range of compounds from high to low polarity
  • Easy maintenance to maximize instrument uptime
  • LabSolutions LCMS workstation software to simultaneously control the LC & MS instruments
  • Mass-it function automatically adds MS results to UV chromatograms

Quick Specs

Mass range m/z 2 to 2,000
Mass Resolution 0.7 u
Scan speed Max. 15,000 u/sec
Polarity switching time 10 msec.



Heated DUIS enables simultaneous analysis of compounds with diverse characteristics

  • Detect high and low polarity molecules in a single run

    The standard ionization source of the LCMS-2050 is a heated dual ion source that combines an electrospray ionization nozzle and atmospheric pressure chemical ionization corona needle. This design makes it possible for you to detect both high and low polarity molecules in a single run and to simultaneously analyze compounds with a wide range of characteristics.

  • Heated DUIS enables simultaneous analysis of compounds with diverse characteristics
Return to Top ^

Environmentally friendly features lower energy consumption and support greener operation

  • Possible 43% reduction in lcms power consumption

  • Reduce running costs and CO2 emissions

    With its small size and single-phase 100 to 240 V specifications, the LCMS-2050 achieves a 43% energy savings compared to the previous model. The Ecology Mode function automatically turns off the unit if you haven’t used it for a set time. The LCMS-2050 is also recognized as an Eco Product Plus under Shimadzu’s proprietary environmentally friendly product recognition system because it limits running costs and CO2 emissions.

Return to Top ^

Seamless LC and MS integration simplifies analysis

  • Easy parameter settings eliminate MS training

    The advanced engineering of the LCMS-2050 makes mass spectrometry as simple to perform as LC detection. You only need the most basic of acquisition parameters to obtain reliable and sensitive detection.

  • Seamless LC and MS integration simplifies analysis
Return to Top ^

Featured Content

Latest Webinar

Learn more

Videos

  • LCMS-2050

    • Single Quadrupole LC-MS

    The LCMS-2050 single quadrupole mass spectrometer combines the user-friendliness of an LC detector with the excellent performance of MS to provide a complete package of easy to use high-level performance and compactness.

  • Experience LCMS-2050: The Compact MS with Countless Benefits

    • Liquid Chromatograph-Mass Spectrometry

    This video provides a quick overview of the new rugged, compact LCMS-2050, which combines the user-friendliness of an LC detector with the excellent performance of MS to provide a complete package of easy-to-use high-level performance.

  • How To Change the Desolvation Line on the Single Quad LCMS-2050

    This video shows you how easy it is to change the Desolvation Line, or inlet capillary, on Shimadzu’s compact, high-performance single quad LCMS-2050 mass spectrometer.

  • How To Change the Probe Position on the LCMS-2050

    • Liquid Chromatograph-Mass Spectrometry

    This video show how quickly and easily the probe position can be changed on the single quad LCMS-2050.

  • Revolutionary Single Quad LC-MS for Drug Development and Quality Control

    • Liquid Chromatograph-Mass Spectrometry

    This webinar will demonstrate an LC-MS system that can perform both LC-MS analysis and LC-UV analysis. This single quad has a small footprint that allows it to adapt to different needs. With the following features, it is hoped that LC-MS will be more commonly used to analyze API, impurities, and perform quality control.
